Seagate ST32151N - Page 71

60 Hawk 2XL Product Manual, Rev. B
Table 11c: “WC” models single ended I/O, 80 conductor cable signal/contact assignments
Notes [ ]: See page following this Table
Signal
Name [1]
Connector
Contact
Number [3]
Cable
Conductor [2]
Connector
Contact
Number [3]
Signal
Name [1]
+12 V CHARGE 1 1 2 41 12 V GND
+12 V 2 3 4 42 12 V GND
+12 V 3 5 6 43 12 V GND
+12 V 4 7 8 44 MATED 1
NC [10] 5 9 10 45 NC [10]
NC [10] 6 11 12 46 GND [8]
-DB11 7 13 14 47 GND
-DB10 8 15 16 48 GND
-DB9 9 17 18 49 GND
-DB8 10 19 20 50 GND
-I/O 11 21 22 51 GND
-REQ 12 23 24 52 GND
-C/D 13 25 26 53 GND
-SEL 14 27 28 54 GND
-MSG 15 29 30 55 GND
-RST 16 31 32 56 GND
-ACK 17 33 34 57 GND
-BSY 18 35 36 58 GND
-ATN 19 37 38 59 GND
-DBP 20 39 40 60 GND
-DB7 21 41 42 61 GND
-DB6 22 43 44 62 GND
-DB5 23 45 46 63 GND
-DB4 24 47 48 64 GND
-DB3 25 49 50 65 GND
-DB2 26 51 52 66 GND
-DB1 27 53 54 67 GND
-DB0 28 55 56 68 GND
-DP1 29 57 58 69 GND
-DB15 30 59 60 70 GND
-DB14 31 61 62 71 GND
-DB13 32 63 64 72 GND
-DB12 33 65 66 73 GND
+5 V 34 67 68 74 MATED 2
+5 V 35 69 70 75 5 V GND
+5 V 36 71 72 76 5 V GND
NC [10] 37 73 74 77 ACTIVE LED OUT
[4] [9]
SCSI ID [2] [5] 38 75 76 78 DLYD-START [6]
SCSI ID [0] [7] 39 77 78 79 SCSI ID [1] [7] [9]
RMT-START [7] [9] 40 79 80 80 SCSI ID [3] [7] [9]
