Hawk 2XL Product Manual, Rev. B 65
Notes.
[1] See SCSI-2 Interface Manual P/N 77738479 (called Volume 2), Section 4.5
[2] Maximum SCSI asynchronous interface transfer rate is given in Section 4.2.3.
[3] Synchronous Transfer Period is determined by negotiations between an Initiator and a Drive. The Drive is
capable of setting periods as given in Section 9.5. See also Sections 3.1.5.2 and 3.5.3.2 of the SCSI-2
Interface Product Manual (P/N 77738479) for a description of synchronous data transfer operation.
General timing diagrams for SCSI interface operation are shown in the SCSI-2 Interface Product Manual
P/N 77738479, Section 4.5. The specific timing values that apply to this drive are listed in Table 12.
Data Out Byte Transfer (parameter) T25 4.5-13 0.04 µs
Next Data In Byte Access (parameter) T26 4.5-12 0.12 µs
Next Data Out Byte Access (parameter) T27 4.5-13 0.12 µs
Data In Byte Transfer (media) [2] T28 4.5-12 0.04 µs
Data Out Byte Transfer (media) [2] T29 4.5-13 0.04 µs
Next Data In Byte access (media [2] T30 4.5-12 0.12 µs
Next Data Out Byte access (media [2] T31 4.5-13 0.12 µs
MSG IN Byte Transfer T32 4.5-5,7,8,14,15 0.04 µs
MSG OUT Byte Transfer T33 4.5-2 0.04 µs
STATUS Byte Transfer T34 4.5-5,8,15 0.04 µs
Synchronous Data Transfer Characteristics:
Request Signal Transfer Period [3] - - various
Description
Waveform
Symbol [1]
Waveform
Table [1] Typical Timing
