15
Using locknut install axle to gear.
Align the wheel pant slot over the axle
bolt as shown. Slide the wheel pant slot
over the at sides of the axle bolt and align
blind nuts in wheel pants with mounting
holes in landing gear. When all bolt holes
are aligned tighten axle in place.
in CA.
3x10mm
M3x4mm
