27
170 mm
Epoxy
Balsa stick.
Epoxy
5) Attach the speed control to the side
of the motor box using two-sided tape
and tie wraps. Connect the appropriate
leads from the speed control to the mo-
tor. Make sure the leads will not interfere
with the operation of the motor.
Speed control.
Open the air exit hole as shown.
Battery.
INSTALLING THE SPINNER.
Install the spinner backplate, propeller
and spinner cone.
