22
BATTERY & RECEIVER.
MUFFLER INSTALLATION.
Install battery using nylon ties and re-
ceiver as shown.
Receiver.
Battery.
COWLING.
1) Gather the materials as shown below.
2) Measure and mark the center of the
template material as shown.
Note: You will use this center mark dur-
ing a later step when aligning template
with cowl.
3) Measure and mark the center of the
bottom of the fuselage as shown. Mount
cowling to fuse and transfer center line
on fuse to bottom of cowl.
To Next Page
