EXTRA 330LX
Instruction Manual.
20
Trim and cut.
INSTALLING THE RECEIVER SWITCH.
Install the switch into the precut hole in
the side, in the fuselage.
3/32” Hole.
.
Switch.
Switch.
INSTALLING THE ENGINE SWITCH.
Trim and cut.
FUEL TANK ASSEMBLY.
Please see below pictures.
