26
3) Attach the electric motor box to the
rewall suitable with the cross lines
drawn on the electric motor box and re-
wall. Using epoxy and balsa stick to se-
cure the motor box to the rewall. Please
see pictures below.
M5x30mm
4) Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M5x20mm hex head bolts to se-
cure the motor. Please see picture shown.
5mm
Blind nut.
M5x20mm
6.5mm
To Next Page
