Seagull Models RV-8 - Engine Mounting Procedure; Mounting the Engine

27
2.
4.
3.
5.
Use a 5.2mm bit to drill the engine
mounting holes.
Remove mounting template from
rewall. Firewall shown with mounting
holes drilled ready for engine mounting.
5.2mm
6.
8.
M5x90mm
7.
Tighten mounting bolts and secure
engine to rewall.
