Seagull Models RV-8 - Final Assembly and Flight Setup; Apply the Decals; Balancing; Control Throws

RV-8 ARF 35-40cc
Instruction Manual.
38
2) If all the decals are not precut, please
use scissors or a sharp hobby knife to cut
the decals from the sheet. Please be cer-
tain the model is clean and free from oily
ngerprints and dust. Position decal on
the model where desired, using the pho-
tos on the box and aid in their location.
1) If all the decals are precut and ready to
stick. Please be certain the model is clean
and free from oily ngerprints and dust.
Position decal on the model where de-
sired, using the photos on the box and aid
in their location.
APPLY THE DECALS
BALANCING
1) It is critical that your airplane be
balanced correctly. Improper balance will
cause your plane to lose control and
crash. THE CENTER OF GRAV-
ITY IS LOCATED 120MM BACK
FROM THE LEADING EDGE OF
THE WING AT THE WING ROOT.
2) Mount the wing to the fuselage. Place a
piece of masking tape on the top of each
wing 88mm back from the leading edge
at the wing root.
3) With the model inverted, place your
ngers on the masking tape and carefully
li the plane. is is the point at which
your model should balance for your rst
ights. Later, you may wish to experiment
by shiing the balance up to 120mm for-
ward or back to change the ying char-
acteristics. Moving the balance forward
may improve the smoothness and arrow-
like tracking, but it may then require
more speed for take o and make it
more dicult to slow down for landing.
Moving the balance a makes the model
more agile with a lighter and snappier
”feel”. In any case, please start at the loca-
tion we recommend.
With the wings attached to the fuselage,
all parts of the model installed ( ready to
y), and empty fuel tanks, hold the model
at the marked balance point with the sta-
bilizer level.
*If possible, rst attempt to balance the
model by changing the position of the re-
ceiver battery and receiver. If you are un-
able to obtain good balance by doing so,
then it will be necessary to add weight to
the nose or tail to achieve the
proper balance point.
1.
120mm
Li the model. If the tail drops when
you li, the model is “tail heavy” and you
must add weight* to the nose. If the nose
drops, it is “nose heavy” and you must
add weight* to the tail to balance.
Ailerons:
High Rate :
Up : 80 mm
Down : 80 mm
Low Rate :
Up : 40 mm
Down : 40 mm
Elevator:
High Rate :
Up : 140 mm
Down : 140 mm
Low Rate :
Up : 70 mm
Down : 70 mm
Rudder:
High Rate :
Right : 120 mm
Le : 120 mm
Low Rate :
Right : 60 mm
Le : 60 mm
CONTROL THROWS
Flap:
Mid : 40mm
Full : 80mm
