29
Install throttle servo into servo mount
ing tray
Reinstall the servo horn by sliding the
connector over the pushrod wire. Center
the throttle stick and trim and install the
servo horn perpendicular to the servo
center line.
6.
5.
7.
8.
servo arm
Move the throttle stick to the closed po-
sition and move the carburetor to closed.
Use a 2.5mm hex wrench to tighten the
screw that secures the throttle pushrod
wire. Make sure to use threadlock on the
screw so it does not vibrate loose.
9.
Epoxy
IGNITION INSTALLATION
1.
I read nylon tie through mounting
holes.
To Next Page
