Seagull Models RV-8 - Fuel Tank and Engine Mounting Preparation; Fuel Tank Installation; Mounting the Engine

RV-8 ARF 35-40cc
Instruction Manual.
26
2.
Switch
1.
2.
FUEL TANK INSTALLATION
4.
Slide the fuel tank into the fuselage. Guide
the lines from the tank through the hole in
the ewall.
You should mark which tube is the vent
and which is the fuel pickup when you attach
fuel tubing to the tubes in the stopper. Once
the tank is installed inside the fuselage, it may
be dicult to determine which is which.
3.
5.
1.
MOUNTING THE ENGINE
