Section 5A – servo & control horn installation (ONLY F3A)
Note: if you chose the MINI servo installation direct in the stabilizer, you can not use the 3D
optional elevators too.
If you want to fly both, F3A elevators and 3D optional elevators, on the same model, go
direct at “Section 5B”, page 15 of this instruction manual.
step 1
Locate the following items, included in the hardware and the mini servo (not included).
Install the servo hardware (gommets and eyelets) included with the servo.
step 2
With the hobby knife open the control horn location.
13
