SECOP P Series - XV COMPRESSORS; XV Compressor Controllers and Wiring

40
22.
XV COMPRESSORS
February 2018 DES.I.300.C4.02 / 520N1205 1/2
Instructions
XV Compressors
160-264V, 50/60Hz
with 105N5xxx
Series Controllers
Attached controller (PFC):
for version105N5320 refer to Instructions DES.I.300.V_
Attached controller:
for version105N5022 refer to Instructions DES.I.300.G_
Detached controller:
for version 105N5052
refer to Instructions
DES.I.300.H_
Connectors:
C = Suction
D = Process
E = Discharge
Recommended tool: 102B8950
Operating Instructions https://www.secop.com/products/technical-literature-operating-instructions/
