MMX
TM
User Guide
23
Unbypassing an active device/circuit
When you unbypass a device or circuit that went into alarm while it was bypassed, you will see the following
message:
If you select “yes” to unbypass this device, the system will immediately go into alarm. To avoid this problem,
press the System Reset button before unbypassing a device or circuit.
Relay Disconnect
This option is useful if you want to disconnect or reconnect the aux relays.
At this point the display will vary, depending on your choice:
• If you selected “yes”, the display will either show the message “Relays disconnected” or “Relays
reconnected”, then it will return to the Command Menu.
• If you selected “no”, the display will show the message “Operation cancelled”, then it will return to the
Command Menu.
Input Zone Bypass
Use this option if you want to bypass an entire zone of addressable devices from the panel. Usually this is done
during building maintenance.
To unbypass the input zone, follow the same procedures for input zone bypass.
Step 1: Select Relay Disconnect
1. Use and to scroll the cursor to “Relay
Disc”.
2. Press to continue.
Step 2: Select “yes” or “no”
1. The systems now asks you whether or not you would
like to bypass the aux relays. Use and to
select “yes” or “no”.
2. Press to continue.
WARNING: Bypassing an input zone will disable all input devices in that loop.
Step 1: Select Input Zone Bypass
1. Use and to scroll the to “Input Zone”.
2. Press to continue.
Warning: This output
device is active.
Do you really want
to unbypass it? Y
- Bypass Menu -
1 Device /Circuit
2 Relay Disc
3 Input Zone
Common aux relays
currently connected
Disconnect? Y
- Bypass Menu -
1 Device /Circuit
2 Relay Disc
3 Input Zone
