Front Panel Menu Operation
26
Audible Test
During this test, alarm activation of any input device will activate all signals for one half second. Trouble activation
on any input device will activate all signals continuously for one second. If audio amplifier is configured for alarm
and trouble events, it will sound words “Alarm” and “Trouble” respectively.
Use and to scroll the cursor through the devices in the Walk Test list. Pressing the up/down keys will
switch the view to display the Walk Test list. This view allows selection of the device to be tested.
Note: Audible devices connected to an addressable output module will not sound in Audible Test mode.
Step 1: Select Audible Test
1. Use and to scroll the cursor to “Audible
Test”.
2. Press when the cursor flashes beside
“Audible Test” to select the Audible Test.
Step 2: Select duration of Walk Test
1. The default duration of Walk Test is 6 hours. To
choose another time duration, use the and
to scroll the cursor to the desired duration time.
Valid range is from 1 hour to 12 hours.
Press to select the Walk Test duration.
Step 3: Start the Walk Test
Start or Resume Test for device inspection.
1. Select Start to begin a Walk Test.
2. Select Resume to continue the Walk Test.
As the test runs, the Alarms and Troubles count will
increase as they are recorded (logged) during the
Audible Test.
Press to end the walk test at any time.
Step 4: Main Walk Test Screen
During the Walk Test the display will be as shown.
A = number of Walk Test alarm events
T = number of Walk Test trouble events
D = number of duplicate alarm and trouble events
R = number of remaining alarm and trouble events from
the Walk Test list
- Walktest -
1 Audible Test
2 Silent Test
- Walktest -
Timeout 6 hours
- Walktest -
1 Start
2 Resume
OneMan
A:xxxx D:xxxx R:xxxx
T:xxxx D:xxxx R:xxxx
Press CANCEL to end
