LCD Programming
press <Enter> to change. Select OK when done. <Clear> returns you to Program
Menu without making changes.
• Test Inhibit: View or change whether common relays are disconnected during Test
Mode or not. <Clear> returns you to Program Menu without making changes.
3.3.3 Switches Menu
This function can be set to Privilege Level 1 or 2. View or change the status of any switches.
These switches can be set to On, Off or Auto. The Auto state only applies to switches that
have a timer associated with them. The Auto state allows the switch to follow the timer
settings. Any changes made are broadcast to the network so that all panels have the same
state. Settings are retained by the panel if it is re-booted and the Master Unit broadcasts its
settings to the network upon start up. See Switches Window for information on programming
what the switch affects.
The menu has the following options:
• Individual: View or change the status of an individual switch. Each switch is shown in
turn. If a switch has no timer, the Auto option is not shown.
• All Off: Force switches into the Off mode. The number displayed is the number of timers
that are switched On. This option is shown only if no switches have timers associated
with them.
• All Auto: Force all switches with timers to Auto mode. All switches with timers go into
the state dictated by the time. The number displayed is the number of switches with
timers forced On or Off. This option has no effect on switches without timers. This option
is not shown if no timers are associated with the switches.
3.3.4 Battery
Displays the current battery status. The display shows:
Line 1: Screen Title
Line 2: AC State (diagnostic use only)
Line 3: Current State of the Battery and Menu Option (see below)
Line 4: Menu Options (listed below)
The menu has the following options:
• OK: Return to Program Menu.
• Test: Force an immediate battery test.
• Calibrate: This function is restricted to Privilege Level 2. This calibrates the Battery
Charger. The batteries must
be disconnected before beginning calibration. No keypad
control is provided during calibration. The calibration display will return when calibration
is over. Calibration only needs to be done when the configuration is erased. All Battery
Chargers come calibrated from the factory.
3.3.5 Addressable
The menu has the following options:
