Appendix D: Table of Reporting Codes
7.0 Appendix D: Table of Reporting
Codes
The following tables contain automatic Contact ID and SIA format reporting codes.
Contact ID: The first digit (in parentheses) will automatically be sent by the control. The
second two digits are to indicate specific information about the signal. For example, if zone 1 is
a fire zone, you could program the event code as [1A]. The central station would receive the
following:
*FIRE* - FIRE ALARM - 1 where the “1” indicates which zone went into alarm.
SIA Format – Level 2: The SIA format used in this product follows the Level 2 specifications
of the SIA Digital Communication Standard – October 1997. This format will send the account
code along with its data transmission. The transmission would look similar to the following at
the receiver:N Ri00 FA 01
N = New Event
Ri00 = System Event
FA = Fire Alarm
01 = Zone 1
Table 1: Automatic Contact ID/SIA Reporting Codes
Reporting Code Code sent when... Dialer
Direction*
Contact
ID Auto
Rep.
Codes
SIA Auto
Rep. Codes
Zone Supv./Rest. zone goes into supervisory/ restore (2) S/R AA See Table 4
Zone Alarms/
Rest.
zone goes into alarm/ alarm condition
has been restored
A/R (1) 3A See Table 4
Zone Trouble/
Rest.
zone exhibits a trouble condition/ zone
trouble condition has been restored
T/R (3) 73 See Table 4
AC Fail Trouble/
Rest.
AC power to control panel is
disconnected or interrupted/AC power
restored; both codes follow the AC
Trouble Delay=
MA/R (3) A1
AT-000/
AR-000
Battery Trouble/
Rest.
control panel battery is low/battery
restored
MA/R (3) A2
YT-000/
YR-000
Ground Fault
Trouble/Rest.
Earth Ground Fault is detected/
restored
MA/R (3) 1A
UT-000/
UJ-000
NAC Trouble/
Rest.
NAC circuit is opened/restored MA/R (3) 21
YA-000/
YH-000
