Appendix A: Condition Codes and Zone Numbers
SSS Sub-Zone Number
Zone Meaning of SubZone Number
Addressable Circuit
000 - Wiring Fault
All Others - Device Number
Comlink 1 (Zone 51) Unit Network ID number
Comlink 3 (Zone 53) Unit ID number
Comlink 6 (Zone 54)
Unit ID Number
1-8 MR-2614
9-16 MR-2644
239 City-tie
240 MRDL/City-tie
Output Supervision (Zone 60) Output Circuit Number
Auxiliary Power Supervision
(Zone 61)
Auxiliary Power Circuit Number
Program Re-start (Zone 69)
000 - Power On/Hard reboot
001 - Watchdog
002 - Clock Monitor
003 - Illegal Instruction
004 - Unused Interrupt
005 - Orphan Interrupt
Privilege Level (Zone 80): Level Set
Switch (Zone 83): Switch Number
