EdgeBox-RPI-200 User Manual
WWW.SEEEDSTUDIO.COM 6
2.2 Connectors and Interfaces
2.2.1 Power supply
Pin#
Signal
Description
1
POWER_IN
DC 9-36V
2
GND
Ground (Reference potential)
The PE signal is optional. If there is no EMI present, the PE connection can leave open.
