EdgeBox-RPI-200 User Manual
WWW.SEEEDSTUDIO.COM 24
4 Electrical specifications
4.1 Power consumption
The power consumption of the EdgeBox-RPI-200 strongly depends on the application, the mode of
operation and the peripheral devices connected. The given values have to be seen as approximate
values.
The following table shows power consumption parameters of the EdgeBox-RPI-200:
Note: On condition of power supply 24V, no add-on card in sockets and no USB devices.
Mode of operation
Current(ma)
Power
Remark
Idle
81
Stress test
172
stress -c 4 -t 10m -v &
4.2 UPS
The backup time of UPS module is very depended on the system load of the system. Some typical
conditions are listed below. The test module of CM4 is 4GB LPDDR4,32GB eMMC with Wi-Fi
module.
Mode of operation
Time(second)
Remark
Idle
55
Full load of CPU
18
stress -c 4 -t 10m -v &
5 Mechanical Drawings
TBD
