EdgeBox-RPI-200 User Manual
WWW.SEEEDSTUDIO.COM 3
1.2.1 Multi-Func phoenix connector
Note
Func name
PIN #
PIN#
Note
POWER
1
2
RS485_A
3
4
RS485_B
5
6
RS485_GND
7
8
DI0-
9
10
DI0+
11
12
DI1-
13
14
DI1+
15
16
NOTE: 24awg to 16awg cable are suggested
