EdgeBox-RPI-200 User Manual
WWW.SEEEDSTUDIO.COM 14
NOTE:
1. All blank signals are NC (not connect).
2. 4G_PWR is the individual power supply for Mini-PCIe card. It can be shut down or turn
on by the GPIO6 of CM4, the control signal is high active.
3. 4G_LED signal is connected to LED2 internally, refer to section of 2.2.8.
4. SPI1 signals are used only for LoraWAN card, such as WM1302.
2.2.12 M.2
EdgeBox-RPI-200 equipped a M.2 socket of M KEY type. ONLY 2242 size NVME SSD card is
support, NOT mSATA.
R79
10K
R0402
VCC_3V3
5V0
R81 22R
R0402
GPIO6
R80
47K
R0402
C69
10uF
C0603
R82
10K
R0402
C70
18pF
C0402
L4
NR3015T2R2M
ind_lps3015
U23
SY8089
sot_23_5
EN
1
GND
2
SW
3
VIN
4
FB
5
4G_PWR
+
C71
22uF
C0805
1
2
+
C72
22uF
C0805
1
2
