Sega Double Spin User Manual

GAME BOARD
91
16
Function O/P Pin
SW1 1
SW2 2
GND 3
+5V 4
VOLUME CONT
5
GND 6
+12V 7
COIN IN
8
GND 9
LOCATION TYPE
J21 9W JST NH
21
22
23
SERVICE
MOTOR PORT A
MOTOR PORT B
1 2 3 4 5 6
7 8 9
Function O/P Pin
STEPPER 0 1
12v 2
STEPPER 1 3
STEPPER 2 4
12v
5
STEPPER 3
6
Function O/P Pin
TOP DC DRIVE
STEPPER 4 1
12v 2
BOT DC DRIVE
STEPPER 5 3
STEPPER 6 4
12v
5
STEPPER 7
6
LOCATION TYPE
J22 6W JST VH - VNR-6N
LOCATION TYPE
J23 6W JST VH - VNR-6N
