6-1-2 FITTING THE BILLBOARD
1
Remove the BACK PANEL by unscrewing the (8) M6x25 Socket Cap Screws.
• Billboard weighs approximately 10kg once assembled. Have at least 2 people
during this operation. Working alone could result in personal injuries, etc.
• To perform work safely and securely, be sure to prepare a step which is in a
safe and stable condition. Performing work without using a step may lead to injury
of damage to components.
M6X25 SKT CAP BLK (8)
To Next Page
