GAME BOARD
16
16-2 GAME BOARD - LOCATION & REMOVAL
● When returning the game board after making repairs or replacements,
make sure that there are no errors in the connection of connectors. Erroneous
connections can lead to electrical shock, short circuits or res.
● When connecting a connector, check the direction carefully. Connectors must
be connected in only one direction. If indiscriminate loads are applied in making
connections, the connector or its terminal xtures could be damaged, resulting in
electrical shock, short circuits or res.
GAME BOARD SERVICE DOOR
GAME BOARD
There is only one access point to the GAME BD which is through the GAME BD SERVICE DOOR located at the
front of the cabinet. Unlock the GAME BD SERVICE DOOR, the GAME BD is located directly behnid the door.
Pull out the draw to improve access.
The machine is tted with Game Board Unit and several other Ancillary Boards which are tted inside the Display
Cabinet. Each machine contains the its own CPU.. Only qualied Personnel should attempt to Service these Units
and before gaining access to the machine, it should be isolated from the
mains supply
