Sega Double Spin User Manual

13
LAMPS AND LIGHTING
68
4
Carefully lower the disc from the top whilst keeping the bottom hinged inplace. Rest the disc on both
handles so that it is possible to disconnect the LED harness.. Once the LED harness has been disconnected
the disc can be removed.
5
Using a Philips screwdriver, remove the (4) M4 machine screws from the centre of the disc.
6
Carefully remove the Inner disc to reveal the LED array.
LED Harness
LED Array (DB-60030UK)
