Sega Double Spin User Manual

TROUBLESHOOTING
15
77
PROBLEM CAUSE COUNTERMEASURE
With main switch ON there
is no activation
Power is not supplied Insert power lead all the way into
outlet
Supply voltage is not correct Make sure that supply voltage is
correct
Circuit protector activated Reset circuit protector/replace
fuse
There is sound and lighting
but no led Display
LED signal connector is not
properly connected
Check connections of the LED
and RedOne connector
No sound Volume not properly adjusted Adjust volume
Poor connection of
connectors
Check connections of RedOne
Board, amp or speaker fault Run speaker test to check.
Switch and volume pot
input does not work
Poor connection or
connectors
Check the connection to RedOne
Feature wheels do not spin Poor connection to motor check the connections to both
upper and lower motors
Poor connection on RedOne Check connections of motor
harness to RedOne
No operation, just a few
static lamps lit
Poor condition of cabinet Refer to list of errors
RedOne error Contact point of purchase
Controller does not work
properly
Improper controller settings Congure settings in TEST mode
Poor attachment of volume
pots or misalignment of gears
Adjust volume pot and set in
calibration settings
Poor connection of
connectors
Check volume pot connections
Volume pot failure Replace volume pot
Game plays but lamp
sequencing and
wheel numbers do not
correspond
Wheel alignment incorrect Realign wheel using Test Menu
Power to redOne inconsistant Check DC5V supply at RedOne
Connections to RedOne
made incorrectly
Check connections against
manual diagram.
No ticket payout Poor connections at ticket
dispenser
Check connections at ticket
dispenser
Poor connections at RedOne Check connections at RedOne
Possible faulty Ticket dispenser Swap ticket dispenser over from
left to right to fault nd
Ticket Jam Clear ticket debris from ticket exit
point.
