16
ASSEMBLY AND INSTALLATION
6
1
Place the ASSY BILLBOARD on to a flat surface and remove the 2x truss screws which secure the Pop
Bracket
FIG. 6-1a
FIG. 6-1b
3
Attatch the Billboard Pop Panel to the Billboard by fitting it between the Pop Bracket and Pop Holder. Se-
cure it in place using the 3x truss screws removed in step 2.
FIG. 6-1c
1 ASSEMBLING THE BILLBOARD
The Billboard can be heavy. Two people are required to install the billboard once assembled..”
2
Once the Pop Bracket has been removed. Undo the 3x truss screws which secure the Pop Holder to the Pop
Bracket.
To Next Page
