15. REPLACEMENT OF FLUORESCENT LAMP
When performing the work, be sure to turn power off. Working with power
on can cause an electric shock or short circuit accident.
The Fluorescent Lamp, when it gets hot, can cause burns. Be very careful
when replacing the Fluorescent Lamp.
To perform work safely and securely, be sure to prepare a step which is in a
secure and stable condition. Performing work without using the step can
cause violent falling down accidents.
Be careful when handling the plastic made parts. Failure to observe this may
cause injury due to damage or fragments resulting from damage.
Remove the 3 screws which secure the Holder on the upper part of Billboard.
Pull out the Holder to the upper side of the Billboard, and replace the fluorescent lamp (32W).
FIG. 15 b
TRUSS HEAD SCREW (3)
M4 X 8, black
BILLBOARD BILLBOARD HOLDER
FLUORESCENT LAMP 32W: 390-5251-32-01
GLOW LAMP: 390-5638-5P
FIG. 15 a
When performing work,
prepare a step.
1
2
To Next Page
