SERVICE MANUAL NAOMI ENG
420-6455-01 (1)
INSTRUCTION MANUAL FOR THE
GAME BOARD
KEY MASTER
220-5576 (2)
For opening/closing the doors
KEY (2)
For the CASHBOX DOOR
The Keys are inside the Coin
Chute Door at the time of shipment
from the factory.
AIR CLEANER
601-8188 (2)
For spare, re
fer to Section 10.
SEAL TAPE
090-0037 (1)
Used for the maintenance of Air Drive,
for air leakage prevention.
VOL CONT B-5K OHM
220-5373
(2)
220-5484
Spare, see Section 12.
TEST MODE WRITING
POSITION
ADJUST
SELECT
RESET
RBG
PIC-ADJ
SET
P
Remote Controller used for
adjustment of the projector.
See Section 14.
200-5536(1)
The Remote Controller is attached to
the Projector at the time of shipment.
5. ACCESSORIES
When transporting the machine, make sure that the following parts are supplied.
TABLE 5 a ACCESSORIES
DESCRIPTION OWNERS MANUAL
Part No. (Qty.)
420-6659-01 (1)
Note
Figures
If Part No. has no description, the Number has not been
registered or can not be registered. Such a part may not be
obtainable even if the customer desires to purchase it.
Therefore, ensure that the part is in safekeeping with you.
