www.seuservice.com
144
18 ASSY MECHA BASE (WRG-3100) (D-1/3)
TORQUE
M10: 27 N•m
M12: 48 N•m
M14: 76 N•m
M16: 95 N•m
M18:110 N•m
M22:170 N•m
Apply greasing to sphere portions
of the rod end
