Seko KEMIDOSE DOUBLE - Technical Specifications

KemiDose | pH · ORP · Chlorine
0000139024 rev. 1.0 EN
4
4. TECHNICAL SPECIFICATIONS
Specifications
KemiDose Double PH/ORP
KemiDose Double PH/ORP/Chorine
Dimensions (H–W–D)
H:196x W:205x D:171 mm
H:196x W:205x D:171 mm
Weight
6 Kg
6 Kg
Pump state
Pause – Supply
Pause – Supply
Probe calibration
Automatic
Automatic
Power supply
220-240 VAC 50-60 Hz
220-240 VAC 50-60 Hz
Consumption (W)
20Watt
20Watt
Device precision
± 0.1 pH; ±10mV; ±1°C
± 0.1 pH; ±10mV; 0.1 ppm; ±1°C
Accuracy
±0,02pH, ±3mV; ±0,5°C
±0,02pH, ±3mV; 0,05 ppm; ±0,5°C
Range
0-14pH; -99 -1000mV; 0…+55°C
0-14pH; -99 -1000mV; 0-5 ppm; 0…+55°C
Flow rate pump (l/h)
5 l/h
5 l/h
Max. back-pressure
5 bar
5 bar
Relay contact (number 3)
250 Vac 10A (resistive load)
250 Vac 10A (resistive load)
Fuse
500 mA (fast)
500 mA (fast)
Frequency pump dosing
160 strokes/minutes
160 strokes/minutes
205.1
194.5
228.15
1850 mm (72.83”)
194.5
