5. Measurement
1. Measuring Ambient Light
In this measurement mode, we have the choice
of shutter priority mode and EV mode. Press the
Mode button
e
to select the Ambient mode.
1-1 Shutter Speed Priority mode
1) Press the Mode button to select
the Shutter Speed Priority mode.
2) Press the Up button y or Down
button u to set the desired shutter
speed.
3) Press the measuring button r to make
a measurement. Release the measuring
button to complete measurement. The
measured value (aperture value) at that
time will be displayed.
While pressing the Measuring button,
the meter measures continuously until
it is released.
REFERENCE: • It is possible to switch between full, 1/2 or 1/3 shutter speeds
with custom setting (see page 19).
• You can set shutter speeds from 60 sec, 50 sec, 45 sec, 1 sec,
0.8 sec through to 0.3sec, 1/4 through to 1/6400 sec and
1/8000 sec. After 1/8000 sec, the cine speed of 8f/s through to
128 f/s can be set.
• After measurement, the F stop value corresponding to the
shutter speed is displayed when the shutter speed changed.
• If ISO film speed is altered after measuring, a corresponding
aperture value will be displayed.
• Even if within the measurement range of the
L-308S, the exposure over symbol E.o may appear for the set
shutter speed at maximum aperture value (F90) and likewise
the exposure under symbol E.u may appear at the minimum
value (F0.5). If either of these symbols appears, please take the
next page action.
