42
2. About Godox Radio System
●
NOTE
● When the measured value display area is touched, both ash waveform graph and measured
value are displayed. When it is touched again, the display returns to the previous screen.
● Measure the ash light characteristics in a darkroom without ambient light.
● To set ISO sensitivity and shutter speed, press the [Flash Duration Analysis Radio
Triggering Mode] Icon ( ) to return to the Measuring Screen.
● The last selected Group in either Flash Power Control Screen or Radio CH/Group Setting
Screen is activated in Measuring Screen.
● For radio CH frequencies, refer to “5. Radio Channel Frequencies”. (
P48)
[Measuring Screen]
[Flash Duration Analysis
Mode Flash Waveform
Graph Screen]
Touching the
Measured
value area
changes the
display.
* The graph screen cannot be used to make measurements.
To Next Page
