35
2. About Godox Radio System
●
Operation
1)
How to use Flash Triggering
1.
Touch the [Measuring Mode] Icon on the Measuring Screen.
The Measuring Mode Screen is displayed.
2.
Touch the [Flash Duration Analysis Radio Triggering Mode] Icon
( ) in Measuring Mode Screen.
When it is selected, the display changes to the Measuring Screen.
The Flash Duration Analysis Radio Triggering Mode can be selected only when the
incident light is set in the meter.
3.
Set the light receiving method.
Switch to the extended lumisphere (
)
or retracted lumisphere ( ).
2-4-4 Flash Duration Analysis Radio Triggering Mode
The meter detects ash brightness after Measuring Button is pressed to send radio
transmitted signal to radio receiver connected to ash. F-stop, ash duration time and
graph of ash waveform are displayed for input ISO sensitivity and shutter speed.
Depending on the receivers in use, the meter controls the output power of ash units
and modeling lamp with turning ON/OFF, however, ash duration time and graph of
ash waveform are not measured in Modeling Lamp Power Control Screen because it is
ambient light not ash light.
Flash Duration Analysis is performed with Incident Light Measuring Mode.
[Measuring Screen] [Measuring Mode Screen] [Measuring Screen]
[Measuring Mode] Icon
To Next Page
