Selco M2500 - Functional Description; Remote Mode Operation; Remote Start Flowchart

SELCO A/S M2500 Installation Manual
Revision: 23-04-2012 Page 29
7 Functional Description
7.1 Remote Mode
In remote mode (terminal 5 connected to com) Start and stop is only available from the REMOTE
START (terminal 08) and REMOTE STOP (terminal 09) terminals.
Provided the engine is ready for remote start (Not Ready LED on the front panel of M2500 is off)
the start procedure works as follows:
Remote Start flowchart:
Start Warning
Fuel Valve on
Engine
running?
Cranking
All start
attempts
completed?
YES
NO
Start Fail
Not ready
Lube Pump
C/B Trip
Air Intake
Common Alarm
Engine Stop
Stop Solenoid
Alarm Relay
Engine ready for
REMOTE START
NO
Start Delay
Survey Delay
Run
Fuel Vanve
Cranking
Fuel Valve on
Rest Time
NO
YES
Engine Running
Run
Fuel Vanve
YES
Remote Start
Command
YES
NO
Lube pump
according config
Ready for remote
start
