ENGLISH - 11
USB
Cigarette lighter adaptor or Power input cable
4. Software Upgrade
USB 2.0 standard has to be only used for upgrade
NOTE
Transfer software program to a USB root folder (not belonging to any other folder) in an empty USB.
i.
ii.
1.
Ensure that the unit is turned off and plug the USB into USB port on the side of controller.
Press and hold TUNE button then also press the POWER button.
Unit will turn on and “USB connected, F/W Update mode” will be shown on LCD.
Once “UPGRADE FINISHED” is shown, update is completed, remove the USB device.
2.
3.
4.
5.
Please go to website www.selfsat.com to download update program (software).
In case a controller does not recognize the USB drive, take the USB out and plug into a PC.
Right click USB folder, go to “Properties” and check if the “File system” is FAT32.
If not, right click USB folder again, go to “Format” and re-setup a file system to FAT32.
CONTROLLER

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SELFSAT SNIPE AIR and is the answer not in the manual?

SELFSAT SNIPE AIR Specifications

General IconGeneral
Gain33.7 dBi
PolarizationHorizontal/Vertical polarization
Elevation angle range-15 - 90 °
Input frequency range10.7 - 12.75 GHz
Output frequency range950 - 2150 MHz
Product colorWhite
Operating temperature (T-T)-20 - 60 °C
Quantity1
Weight and Dimensions IconWeight and Dimensions
Depth192 mm
Width515 mm
Height355 mm
Weight10900 g
