GERMAN - 21
F-2
SAT>IP WLAN kabel, Controllerkabel, Empfängerkabel, Kabelhalter und Kabelverschraubung erforderlich.
Legen Sie und halten Sie die montierten
Kabelhalter im Inneren der Bandmarkierungen.
Bohren Sie drei (3) 2mm Löcher
Kabel Halterung am Fahrzeugdach mit drei (3)
von M4 x 20 Schrauben auf Bohrungen gemacht
F-4F-3
Tragen Sie Silikon rund Kabelhalter und auf der
Oberseite der Schrauben für wasserdichte
Schließen Sie die Kabel, um die relative Ports.
Entfernen Reibungsband dann aufgeräumt
Silikon vor Trocken
F-6F-5
F-1
Legen Sie Kabel wie auf dem Bild
F. Kabelhalter Installation 2
