SPIDER RT1 Motorcycle Mesh Communication System | 13
2 INSTALLING THE HEADSET ON YOUR HELMET
2.3.2 Using the Wired Microphone
If you have a full face helmet, you can use the wired microphone.
1. Peel off the cover of the hook and loop fastener for wired microphone
to expose the adhesive tape. Then, attach the hook and loop fastener
on the inside of the helmet’s chin guard.
2. Attach the wired microphone to the hook and loop fastener for wired
microphone.
3. Align the arrows on the main unit and microphone cables and insert
the microphone cable into the microphone connector.
Note: The shortest cable is for the microphone.
2.4 External Mesh Intercom Antenna
Pull the Mesh Intercom Antenna inwards
slightly to unfold it.
1
2
1
2
