19
This tool is equipped with an
adjustable belt hook. Remove the
knurled fastener to raise or lower
the hook. Switch the position of the
mounting plate on the opposite side
for left-handed operators.
Whenever possible, hold the tool at
a right angle to the work surface.
» Indicator LED
OFF
» LED indicador–
Apagado
» Voyant DEL–
éteint
Always turn the tool off before stor-
ing. As an added protection feature,
the tool will automatically turn off
35 minutes after the last activation.
Turn the tool off by depressing
the selector switch towards either
mode symbol for approximate ly 1
second, then remove battery.
Wear safety glasses when opening
the E-Z clear latch.
Release the feeder shoe and slide
it forward. Remove fasteners from
the tool.
Release E-Z Clear latch and pull
magazine away. Magazine will
completely disengage.
Pull magazine door latch back to
reveal fastener strip.
Remove strip.
