Remove jammed fastener. Attach
the magazine and latch.
Remember! The Fusion tool is
charged with compressed air in a
factory sealed chamber.
Do not tamper with the drive as-
sembly.
Place battery pack in charger. Align
raised ribs on battery pack with
groove in charger.
Press down on battery pack to
be sure contacts on battery pack
engage properly with contacts in
charger.
When properly connected, red light
will turn on. Red light indicates fast
charging mode.
Authorized
Service
Center
Red and green light ashing
indicates defective battery pack.
Return battery pack to your nearest
SENCO Authorized Service Center
for inspection or replacement.
Flashing Red indicates an over-
heated battery. Charging will begin
after battery cools.
Solid red indicates that the battery
is charging.
When battery pack is fully charged,
the red light will turn off and the
green light will turn on.
20
