ASM 988A – Manual
18
APPENDIX A: CABLE PINOUTS
M2P Transport Stream Input Port
13 1
25 14
Pin Number Connection
1 CLOCK OUT +
2 CLOCK IN +
3 INPUT SYNC +
4 INPUT DATA VALID +
5 INPUT D0 +
6 INPUT D1 +
7 INPUT D2 +
8 INPUT D3 +
9 INPUT D4 +
10 INPUT D5 +
11 INPUT D6 +
12 INPUT D7 +
13 GROUND
14 CLOCK OUT -
15 CLOCK IN -
16 INPUT SYNC -
17 INPUT DATA VALID -
18 INPUT D0 -
19 INPUT D1-
20 INPUT D2-
21 INPUT D3-
22 INPUT D4-
23 INPUT D5-
24 INPUT D6-
25 INPUT D7-
