APPENDIX B: SOFTWARE TREE
Table 1 illustrates the menu tree accessible through the front panel. This table is
structured from left to right, where menus to further to the right are submenus.
Root Submenu Submenu Submenu
Input Signal DVB-ASI
ASI Sync Clock
DVB-SPI
M2P Sink Clock
M2P Source Clock
Inv PN-23
PN-23 Normal
Modulation Format Adv QPSK, Rate 3/4
Adv QPSK, Rate 1/2
Adv QPSK, Rate 1/4
DSS-QPSK, Rate 6/7
DSS-QPSK, Rate 2/3
DSS-QPSK, Rate 1/2
QPSK DVB Legacy, Rate 7/8
QPSK DVB Legacy, Rate 5/6
QPSK DVB Legacy, Rate 3/4
QPSK DVB Legacy, Rate 2/3
QPSK DVB Legacy, Rate 1/2
Adv 16 QAM , Rate 3/4
8 PSK Turbo, Rate 8/9
8 PSK Turbo, Rate 5/6
8 PSK Turbo, Rate 3/4 (2.10)
8 PSK Turbo, Rate 3/4 (2.05)
8 PSK Turbo, Rate 2/3
IF Frequency (MHz) 50.000000 to 90.000000
Symbol Rate (Msps) 0.256000 to 30.000000
Payload Rate (Mbps) 0.5 to 85 Mbits/s
Attenuation (dB) +5 to -20dBm
Spectrum Normal/Inverted
Alpha 0.10 – 0.50
CW Test Enable/Disable
IF Output Muted Enable/Disable
Delete Sync Byte Enable/Disable
System Parameters System Date and time Set the date and time
Daylight Savings Enable/Disable
Clock 24hr Mode Enable/Disable
System Temperature
IP Set Static, DHCP, Off + IP adress
Software Revision
Xilinx Revision
Mute on start up Enable/Disable
Fault Settings
Reset Fault History Indicator
Reset Fault Log File
Fault Log Defear, 5 min, 15 min, 30 min, 1 hr, 12 hr, 1 day
Relay 1 Settings Master, Input, Output, Fan, Volt, Temp.
Relay 2 Settings Master, Input, Output, Fan, Volt, Temp.
Relay 3 Settings Master, Input, Output, Fan, Volt, Temp.
View Faults Current Fault
View Fault Log
Reset System
SNMP Settings Set IP manager Address 1 Enable/Disable
Set IP manager Address 2 Enable/Disable
Set IP manager Address 3 Enable/Disable
Set IP manager Address 4 Enable/Disable
Set IP manager Address 5 Enable/Disable
To Next Page
