VP400 Series Video Pro Form7343A Operation Manual
43
APPENDIX A
Sencore VideoPro Pixel Resolution
Format VideoPro min pixel Format VideoPro min pixel
Format pixel clk pixel clk resolution Format pixel clk pixel clk resolution
VESA ATSC
640x350_85Hz 31,500 31,500 1 480i29 13,500 13,500 1
640x400_85Hz 31,500 31,500 1 480i30 13,513 13,513 1
640x480_60Hz 25,175 25,175 1 480p59 27,000 27,000 1
640x480_72Hz 31,500 31,500 1 480p60 27,027 27,027 1
640x480_75Hz 31,500 31,500 1 720p59 74,175 74,175 1
640x480_85Hz 36,000 36,000 1 720p60 74,250 74,250 1
720x400_85Hz 35,500 35,500 1 1080i25 74,250 74,250 1
800x600_56Hz 36,000 36,000 1 1080i29 74,175 74,175 1
800x600_60Hz 40,000 40,000 1 1080i30 74,250 74,250 1
800x600_72Hz 50,000 50,000 1 1080p50 148,500 148,500 1
800x600_75Hz 49,500 49,500 1 1080p59 148,351 148,351 1
800x600_85Hz 56,250 56,250 1 1080p60 148,500 148,500 1
1024x768_42Hz 44,899 44,899 1 1080p24 74,250 74,250 1
1024x768_60Hz 65,000 65,000 1 1080p24sF 74,250 74,250 1
1024x768_70Hz 75,000 75,000 1
1024x768_75Hz 78,750 78,750 1 CUSTOM
1024x768_85Hz 94,500 94,500 1 848x480_60Hz 33,749 33,749 1
1152x864_75Hz 108,000 108,000 1 1024x576_60Hz 47,249 47,249 1
1280x960_60Hz 108,000 108,000 1 1280x720_60Hz 76,591 76,591 1
1280x960_85Hz 148,500 148,500 1 1360x768_60Hz 85,499 85,499 1
1280x1024_60Hz 108,000 108,000 1 1365x1024_60Hz 119,999 119,999 1
1280x1024_75Hz 135,000 135,000 1 1365x1024_75Hz 144,000 144,000 1
1280x1024_85Hz 157,500 78,750 2 1440x960_72Hz 129,024 129,024 1
1600x1200_60Hz 162,000 81,000 2 960p59 107,999 107,999 1
1600x1200_65Hz 175,500 87,750 2
1600x1200_70Hz 189,000 94,500 2 HDTV/SDTV DVI DVI VESA/Mac
1600x1200_75Hz 202,500 101,250 2 480i29 640x480_60
1600x1200_85Hz 229,500 114,750 2 480p59 640x480_75
1792x1344_60Hz 204,750 102,375 2 720p59 640x480_85
1792x1344_75Hz 261,000 130,500 2 1080i29 720x400_85
1856x1392_60Hz 218,250 109,125 2 480i29LH 800x600_60
1856x1392_75Hz 288,000 144,000 2 480i29SH 800x600_72
1920x1440_60Hz 234,000 117,000 2 480i30 800x600_75
1920x1440_75Hz 297,000 148,500 2 480p59LH 800x600_85
480p60 1024x768_60
Mac 540p59 1024x768_70
640x480_67Hz 30,240 30,240 1 720p60 1280x768_60
832x624_75Hz 55,000 55,000 1 1080s23 1280x768_75
1024x765_75Hz 80,000 80,000 1 1080s24 1280x768_85
1152x870_75Hz 100,000 100,000 1 1080s25 1280x1024_60
1080i30 640x480_67
NTSC/PAL 1080p23 832x624_75
NTSC 14,318 14,318 1 848x480_60
NTSC_Y 14,318 14,318 1 SDI 852x480_60
PAL 17,750 17,750 1 487i29
PAL_Y 17,750 17,750 1 576i25
RS170Y 14,318 14,318 1 HDSDI
NTSC_RGB 14,318 14,318 1 720P@50, 59, 60
PAL_RGB 14,318 14,318 1 1080i@25, 29, 30
1080p@25, 29, 30
1080x@23, 24
