Dismantling pump tube
Removing entry tube Dismantling entry tube
Dismantling the pump
'LVFRQQHFWWKHVXFWLRQWXEH$DQGWKHYDOYHWXEH
(V) from the stub (Z);
Take out the ferrules (X1) and (X2), the tube (Y) and
WKHVWXE%E\SXOOLQJKRUL]RQWDOO\)LQDOO\H[WUDFW
the washer (G) from the stub B;
2SHQWKHFDWFK$DQGUHPRYHWKHHQWU\WXEH&
by pulling downwards;
Extract the joint (A) and non-return valve (B) from
the entry tube (C);
ΖQRUGHUWRH[WUDFWWKH%RG\RIWKHSXPSSUHVVWKH
catch located on its left and, keeping it pressed, ro-
tate the body anti-clockwise until it is freed. Then
remove the pump by pulling outwards.
