Assemble the pump tube in the pump
Put upper tray in place
Put the tank and the tray in place
Carefully introduce the product pump tube into the
peristaltic pump. Verify that the tube is positioned
in the centre of the compressor rollersΖQVHUWWKH
valve tube.
Put the upper tray back into the refrigerator.
Place the product tanks with their covers and the
lower trays back into the refrigerator. Connect
the level sensor and the suction tube carefully to
the tank lid;
3.5 3.6
Close pump
Close the lid of the pump and put the bolt in place.3.3 3.4
