26
A
3. Remove the cover for the spooling device.
4. Remove the bolt, washer, key and gear.
Key
Bolt
Cover
WasherGear
5. Turn the helix screw by hand until the rope guide comes to the outmost position
on the same side as the rope wedge pocket.
Front view
Rope guide to the
outmost position
Helix screw
Top view
Turn by hand
Installation
