28
– For installation of electric components see attached appendix.
– For installation of remote control see attached appendix.
Recommendations:
– Install illumination for the controls at the operation station and working lights.
3.8 Electrical installation
The emergency stop shall cut out the power supply to the winches.
WARNING
3.9 After installation
Test all functions to see if they work properly before using the winch.
Check:
– Control (moves easily).
– Emergency stop (function).
– Wire rope and attached devices (free from damages).
– Hydraulic system (no oil leakage).
– Level of hydraulic oil in the oil tank (tank lled to 80%).
– Illumination.
Installation
