27
Key
Bolt
Cover
WasherGear
The marking on the follower should now be pointing to the centre spot.
Note
The location of the punched marks can be different between different winch
models.
6. Ret the gear and the cover, secure the center bolt with Loctite.
7. Ret the cover on the rope guide.
8. Attach the rope in accordance to the instruction, Rope installation.
Follower
Rope guide
Installation
