39
3.2 Hydraulic oil tank
3.3 Return oil lter Must lter to 10 microns or better and
accept required oil ow.
3.4 Pipe, hoses and
connectors
Must be approved for min. 25 MPa
(250 bar) working pressure and have
the following dimensions:
- Pump inlet line min. 1 1/4”
- Return line min. 1”
- Pressure lines hose 1/2” - 3/4”
- pipes min. Ø16 x 2 mm
- Pilot line, pipe min. Ø8 x 1 mm
Winch basics
